High Speed Automotive Wire Braiding Machine
A wire braiding machine is a piece of indispensable major machinery in the industry. In short, it is a machine that weaves wires one by one to enhance the toughness of wires. Let's understand its working principle.
Working principle of wire braiding machine:
The wire braiding machine is to uses the spindle to make a sinusoidal circular motion along with the guide disc, and braid the steel wire according to certain rules. The steel wire is simply installed on the spindle, and the spindle is equipped with a spring to make the steel wire have a certain tension. The odd and even number of two groups of spindles cross each other and move in the same circular motion of the sinusoidal curve. The advantages of this wire braiding machine are summarized as follows:
1. The wear resistance of the guide disc is increased and the hardness of the guide disc is added to make it more durable.
2. The structure of the transmission part is more reasonable, which increases the stability of the equipment operation, reduces the working noise, and makes the operation simple.
3. The chain traction mechanism of advanced equipment is adopted in the traction part, which avoids the disadvantage of quick-wear of worm wheel and worm in the past, making it easier to maintain, more durable, and practical.
4. The motor is powered by a frequency conversion system, which increases the weaving speed and saves 15% - 50% of electric energy.
